Product Details:
|
| Condition: | New | Capacity: | 3.5m3, 3.5m3/3500liters |
|---|---|---|---|
| Dimension(L*W*H): | 1812*1812*4711mm | Weight: | 2900kgs |
| Warranty: | 1 Year | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Item: | Cryogenic Pressure Tank (LO2,LN2,LAr) | Medium: | LO2,LN2,LAr |
| Working Pressure: | 8bar/16bar | Type: | Vertical/horizontal |
| Color: | White | Insulation: | Vacuum Powder |
| Application: | Liquid Storage Tank | MOQ: | 1 Unit |
| Port: | Shanghai | ||
| High Light: | ISO9001 cryogenic oxygen storage tanks,liquid oxygen storage tank 3500 liters,high pressure liquid oxygen storage tank |
||
Main Parameters
1. Storage medium: LO2, LN2, LAr, LCO2 or LNG.
2. Working pressure: 0.2MPa-3MPa
3. Working temperature: determined by the medium
4. Effective capacity: 3m3-20000m3
5. Manufacturing standards: A2, C2, GC1, GB-150, ASME, U STAMP, ISO9001:2008
Applications
The vacuum insulated cryogenic tank is widely used in machinery, chemical, chemical fiber, medical, food, metallurgy, mining, electronic and military industries.
Features
1. good durability and security.
2. compact structure, small footprint, centralized control.
3. excellent heat preservation, small evaporation loss.
4. easy operation and maintenance.
| Product Name | For sale high pressure transport truck liquid oxygen gas cryogenic storage tank | ||||
Model | Storage medium | Effective volume(m3) | Max working pressure (Mpa) | Main material | Dimension (mm) |
ZCF-20000/8 | LO2,LN2,LAr | 20 | 0.78 | 06Cr19Ni10/ | 2416X10106 |
ZCF-50000/8 | LO2,LN2,LAr | 50 | 0.92 | 06Cr19Ni10/ | 3124X12731 |
| ZCF-100000/8 | LO2,LN2,LAr | 100 | 0.92 | 06Cr19Ni10/ | 3624X17355 |
CF-25000/6 | LNG | 25 | 0.6 | 06Cr19Ni10/ | 2420X11000 |
ZCF-5/22 | LCO2 | 5 | 2.16 | 16MnDR/ | 2016X4942 |
|
| Item | Delivery time |
| Tank | 3-4 months |
| Trailer | 4 months |
| Cryogenic liquid pump | 10 days to 1 month |
| Vaporizers | 15 days |
| Complete set of equipment | 3-10 months |
| Dry ice machine | 25 days |
We are proud to have an experienced and passionate elite team. We have always been a pioneer in the industry, to keep competitive in the world market. Our team will be constantly committed to exploring the gas field, providing customers with a variety of tailor-made solutions for air resource exploitation.
As a top two brand in cryogenic equipment with almost 50 years history, We specialize in producing air separation units, LCO2 recovery plants, LNG plants, cryogenic liquid storage tanks(LO2, LN2, LAr, LCO2, LNG and LPG), cryogenic mobile tanks, semi-trailer tankers, vaporizers, gas filling stations,gas cylinders and dewars, dry ice making machines, dry ice blasting machines and cryogenic pumps etc.
In the gas equipment field, we are proficient in both design and manufacture, enjoying a good reputation worldwide. By our consistent efforts, we turned the invisible air into visible brilliance. With 50 years of experience, we can provide customers with a complete range of products and the most professional services. Taking advantage of the group company structure, we have an in-depth and comprehensive understanding of market. Customers can get all they need at one-stop purchase.
Our Mission:
Professional staffs are employed to serve the customers. The high quality and low price can ensure the customer dominating the marketing.
Buyer Reading
1. Q: What products I can order from your company?
Re: We specialize in producing air separation plants, CO2 recovery plants with or without source gas, cryogenic liquid storage tanks (LO2, LN2, LAr, LCO2, LNG and LPG), ISO tanks, semi-trailer tankers, vaporizers, LPG and LNG filling stations, cylinders and dewars, dry ice machines, compressors and cryogenic pumps etc. Any interests you can feel to contact us for details. Thanks.
2. Q: What is your production standard? Can you manufacture your products under ASME standard?
Re: Our products are designed, manufactured and tested as per reference standards of GB150, Safety technology supervision regulations of pressure vessels and some other reference Chinese standards.
Our company has obtained the A2 and C2, C3 Pressure Vessel Fabrication Certificates, Grade GC1 Pressure Pipe& Vessel Construction Certificates, ISO9001 Quality Certificate, ASME Certificate and U Stamp. So, if you ask for ASME stamp, we are able to manufacture your products under ASME standard.
3. Q: What’s the difference between Chinese GB standard and ASME standard?
Re: Our GB standard on PV is equivalent to ASME VIII and GB electrical standards are equivalent to IEC standards, for electrical products.
The following are used by European countries for export in Gulf and all of them have equivalent Chinese standards as per WTO rule.
- DIN-Standards
- VDI/VDE-Regulations
- IEC-Standards
- AD-Specifications
- UVV-Regulations
We can send you a document specifying relationship between GB150 and ASME on your request.
4. Q: Have you supplied tanks to any renowned companies?
Re: Our group company is a regular strategic partner of some big gas companies. We have supplied many storage tanks for them with different sizes. The biggest size we ever provided is 3000m3 ordinary pressure storage tank. We also made high pressure storage vessels for them, such as 100m3 LCO2 tanks, 10m3 (20m3, 30m3)LO2 (LN2, LAR) tanks.
As a giant cryogenic equipments company with more than 40 years history, we are a top two manufacturer producing air separation plants in China. The biggest air separation plant we have ever made is 60,000Nm3/h, famous for its advanced technology and reliable performance.
