Ethylene Hydrocarbon Recovery Stainless Steel Cold Box LNG 110bar

Certification
China Sichuan Air Separation Plant Group certification
China Sichuan Air Separation Plant Group certification
I'm Online Chat Now

Ethylene Hydrocarbon Recovery Stainless Steel Cold Box LNG 110bar

Ethylene Hydrocarbon Recovery Stainless Steel Cold Box LNG 110bar
Ethylene Hydrocarbon Recovery Stainless Steel Cold Box LNG 110bar Ethylene Hydrocarbon Recovery Stainless Steel Cold Box LNG 110bar

Large Image :  Ethylene Hydrocarbon Recovery Stainless Steel Cold Box LNG 110bar

Product Details:
Place of Origin: China
Brand Name: SASPG
Certification: ASME/CE/GB
Model Number: Cold box LNG,Heat exchanger, Hydrocarbon recovery, ethylene,CO2 recovery,
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: container, wooden case ,bulk
Delivery Time: 8months-18months
Payment Terms: L/C, T/T
Supply Ability: 50 Sets / Year

Ethylene Hydrocarbon Recovery Stainless Steel Cold Box LNG 110bar

Description
Condition: New Material: Stainless Steel, Carbon Steel, Aluminum
Application: Petrochemical, ASU,Gas, Hydrocarbon Recovery, Ethylene,CO2 Recovery Pressure: 110bar
High Light:

ethylene Cold box LNG

,

ethylene Hydrocarbon recovery LNG

,

Stainless steel Cold box LNG 110bar

Cold box LNG,Hydrocarbon recovery, ethylene,CO2 recovery,



Project and Engineering services, Sichuan Air Separation Plant (Group) Co., Ltd. (Hereinafter called SASPG) shall design, manufacture and supply a brand-new air separation plant with the latest process technology of molecular sieve adsorption, booster turbo-expander, structural packing upper column and GOX internal compression process. This plant is complete with the air filtration system, air compressor system, air pre-cooling system, molecular sieve purification system, booster turbo-expander system, cold box system, LOX storage & vaporization system, instrumentation and electric control system etc.



A detailed brochure is attached with our offer which includes our company organization, structures and capabilities, a brief introduction to SASPG follows:



  • SASPG was established in 1966
  • Plant building covered area – 321715 m2
  • Staff - 3000
  • Total Assets – 334 Million USD
  • Annual Turnover – 300 Million USD
  • Production Capacity – 50000 Tons
  • Plant capacities – 50 Nm3/hr up to 60000 Nm3/hr
List of Performance on Cold Box & Heat Exchanger-SASPG
No. Model Dimension
(L×W×H)mm
Working Pressure
Mpa
Associated Equipment Process
Applied
User Production Time
1 CB029.000 6700×2000×2410 6.6 Model LNG-1650 Cold Box Nitrogen Expansion CNPC Chengdu Natural Gas Chemical Company 2005.8
2 BJ1088.000 3600×400×480 3.1 6×104Nm3/d Natural Gas Liquefaction Nitrogen Expansion Ameirica CCSI 2007.9
3 CE502.000 11500×3700×3000 5.0 10×104Nm3/d Natural Gas Liquefaction Nitrogen Expansion(Two stages) Chengdu Yonglong Natural Gas Co., Ltd 2007.9
4 CE503.000 18000×4000×3000 6.0 20×104Nm3/d Natural Gas Liquefaction Nitrogen Expansion(Two stages) LNG (CE)Exported to Poland 2007.1
5 CE504.000 12000×3400×3200 5.5 30×104Nm3/d Natural Gas Liquefaction Device Nitrogen and Methane Expansion Ningxia Funing Group 2008.9
6 CE505.000 12000×3400×2400 5.5 13×104Nm3/d Natural Gas Liquefaction Device Nitrogen Expansion(Two stages) Erdos Xinsheng Natural Gas Company 2008.11
7 E507.000 14900×6000×6000 5.7 200×104Nm3/d LNG Mixed Refrigerant HQCEC 2011.6
8 L048.000 7860×3500×3200 3.0 40×104Nm3/d Helium concentrated from natural gas+LNG Methane Expansion+Nitrogen Recycling Chengdu Natural Gas Chemical Company 2010.1
9 CE506 27500×4500×3800 4.7 60×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Inner Mengolia Xinsheng Project Phase II-Erdos Hangqi Xinsheng Natural Gas Company 2011.11
10 CB070 9000×2700×2600 6.0 5×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Erdos Qingyuan Natural Gas Company 2011.1
11 BJ8232 11500×3200×3000 5.5 10×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Guangdong Dongguan Jiufeng 2011.1
12 HTLG250000.000 11000×4000×3800 6.4 25×104Nm3/d Coal-bed Gas
Liquefaction
Nitrogen Expansion(Two stages) Shanxi Energy Coal-bed Gas Investment Holding Ltd. 2011.12
13 BJ8237 8000×1200×1390 6.0 20×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Harbin Cryogenic Liquified
Gas Equipment Co., Ltd-
Changchun Project
2011.6
14 BJ8238 1400×1000×1060 6.0 30×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Harbin Cryogenic Liquified
Gas Equipment Co., Ltd-
Baotou Project
2011.6
15 HTLG200000.000 11500×3200×3000 6.0 20×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Gansu Yongjing Natural
Gas Company
2011.9
16 E509.000/HTLG
95000000.000
24000×5000×4000 3.5 30000Nm3/h Liquid Natural Gas made from Coke Oven Gas Mixed Refrigerant Henan Jingbao Xinao
Energy Co.,Ltd.
2013.5 Start-up
17 E512.000 22000×4500×3500 5.5 30×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Luyang Lake Shanxi Zhongyuan Green Energy Natural Gas Co.,Ltd. 2012.4
18 E511.000 24000×4500×3800 5.5 100×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Inner Mongolia Guoneng
Xinxing Energy Co., Ltd
2012.5
19 E512.000 24000×4500×3800 5.5 100×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Zhangjiakou Guochu Liquefied
Natural Gas Company
2012.5
20 E509.00000 29000×8000×5500 4.5 430×104Nm3/d LNG Recycled from
Coke Oven Gas
Mixed Refrigerant Yunnan Xianfeng Jiehua 2013.12 Start-up
21 E513.000/HTLG300K.000 22000×3400×3400 6.0 30×104 Nm3/d Natural Gas Liquefaction Mixed Refrigerant Langfang Jubang Gas Company 2012.6
22 E514.000 29500×4900×3900 6.6 Shandong Tai'an 600,000 tons/year(260×104Nm3/d)LNG Equipment Domestication Mixed Refrigerant Shandong Taian Kunlun
Energy Co., Ltd.
2013.8
23 E515.000 24000×5500×3800 5.9 200×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Erdos Hangqi Xinsheng Natural Gas Company 2013.9
24 BJ8274.000 8100×1200×1734 5.9 30×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Harbin Cryogenic Liquified
Gas Equipment Co., Ltd-
Shandong Dezhou Project
2012.9
25 BJ8275.000 7500×1000×1243 5.0 30×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Harbin Cryogenic Liquified
Gas Equipment Co., Ltd-
Daqing Project
2012.1
26 LNG006.000 13000×3500×3500两台 5.6 60×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Shandong Yucheng Huayi
Natural Gas Company
In execution
27 LNG002.000 8000×5100×3800 5.5 500×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant CPC Hubei 2013.5
28 BJ8289.000 8000×1200×1251 3.8 3×100×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Harbin Cryogenic Liquified
Gas Equipment Co., Ltd-
Shandong Heze
2012.6
29 BJ8290.000 8000×1200×1628 6.0 30×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Harbin Cryogenic Liquified
Gas Equipment Co., Ltd-
Inner Mongolia Wanji
2012.8
30 E518.000 18000×4400×3200 3.0 30000Nm3/d LNG made from
Coke Oven Gas
Mixed Refrigerant Hegang Henan Economic &
Business Co., Ltd.
2013.1
31 LNG003.000 11000×3000×2800 6.5 10×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Hubei Lichuan Minsheng
Energy Holding Company
2013.11
32 LNG005.000 13000×3500×3500 6.2 30×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Wuhan Ganghua Energy
Co., Ltd.
2013.11
33 CBJ8296.00000 10000×3200×3000 5.5 150×104Nm3/d LPG(MRC Process) Mixed Refrigerant CNPC Shunan Gas Field 2013.12
34 E519.00000 Heat Exchanger
14000×3200×5000
4.0 40000Nm3/h Liquefied Natural Gas made from Coke Oven Gas Mixed Refrigerant Tangshan Tanggang Gas
Co., Ltd.
2013.12
Column
25000×3200×5000
4.0
35 E520.00000 29000×8500×6000 4.5 480×104Nm3/d LNG recycled
from Coke Oven Gas
Mixed Refrigerant Xinjiang Xinye In execution
36 CBJ8304.00000 9000×2200×2700 7.4 2×5×104Nm3/d Natural Gas Liquefaction Mixed Refrigerant Saipu Ruixing In execution
37 CBJ8309.00000 7000×2200×1800 3.1 LNG(two sets)   Sinopec Luoyang
Engineering Co., Ltd.
In execution
38 CBJ8315.00000 12000×3800×3000 5.3 30×104Nm3/d Natural Gas
Liquefaction
Mixed Refrigerant Yunnan Fushui Zhongcheng Natural Gas Co., Ltd. 2014.3
39 LNG009.000 12000×3500×3300 5.5 30×104Nm3/d Natural Gas
Liquefaction
Mixed Refrigerant Aerosun Holding Co., Ltd. In execution
40 LNG008.000 13000×5400×3500 5.4 60×104Nm3/d Natural Gas
Liquefaction
Mixed Refrigerant The CPC Natural Gas Co., Ltd. Guangdong Zhaoqing 2014.6
41 E516.000 13000×3800×3600 5.5 27.1×104Nm3/d Natural Gas
Liquefaction for Gate Station
Methane
Expansion
Wuhan Zhongneng Xingye Energy Co., Ltd. In execution
42 LNG013.000 24000×5000×3200 14000×5000×3200 3.5 70000Nm3/h LNG made from
Coke Oven Gas
Mixed Refrigerant Shandong Weijiao Group
Xuecheng Energy Co., Ltd.
In execution
43 LNG011.000 24000×5200×3400 3.8 LNG-15500 Enriched Methane
Gas Liquefaction Device
Mixed Refrigerant Sichuan Dakete Energy
Technology Co., Ltd.
In execution
44 LNG010.000 19000×4100×3300 6.5 BOG Recycling System in Yudong
LNG Project
Mixed Refrigerant CNOOC Yuedong Liquefied
Natural Gas Co., Ltd
In execution
45 CE521.00000 25000×3200×3200 24000×5000×3800 4.7 50×104Nm3/d Natural Gas
Liquefaction
Mixed Refrigerant Ningxia Yanchi In execution
46 CBJ8345.0000 9200×2200×2500 6.2 5×104Sm3/d Skid-mounted Natural
Gas Liquefaction Device
Mixed Refrigerant Shandong Sairui Petroleum
Technology Development
Co., Ltd.
In execution
47 CE525.00000 27500×4500×3800 4.7 60×104Nm3/d Natural Gas
Liquefaction
Mixed Refrigerant Henan Jiaozuo Boai
Shanxia Yizhong
In execution
48 CE526.00000 15000×5700×3800 4.5 50×104Nm3/d Natural Gas
Liquefaction
Mixed Refrigerant Shanxi Qinshui In execution
49 CE523.00000 25000×5800×3700 3.4 30000Nm3/h LNG made from
Coke Oven Gas
Mixed Refrigerant Heilongjiang Shuangyashan
Jianlong Chemical Company
In execution
50 CE524.00000 25000×5800×3700 3.5 30000Nm3/h LNG made from
Coke Oven Gas
Mixed Refrigerant Henan Liyuan In execution
51 CE522.00000 24000×5500×3800 5.8 100×104Nm3/d Natural Gas
Liquefaction
Mixed Refrigerant Shanxi Qingjian In execution
52 LNG014.00000 12000×2700×2000 6.0 2×3×104Nm3/d Natural Gas
Liquefaction
Mixed Refrigerant Jierui Natural Gas
Engineering Co., Ltd.
In execution
53 LNG015.00000 12000×2700×2000 6.0 3×5×104Nm3/d Natural Gas
Liquefaction
Mixed Refrigerant Jierui Natural Gas
Engineering Co., Ltd.
In execution
54 LNG016.00000 12000×2700×2000 6.0 7×104Nm3/d Natural Gas
Liquefaction
Mixed Refrigerant Jierui Natural Gas
Engineering Co., Ltd.
In execution
55 CBJ8362.00000 9500×2200×3500 5.3 15×104Nm3/d Natural Gas
Liquefaction
Mixed Refrigerant CPE Chongqing Dianjiang In execution
56 LNG017.00000 15000×7000×3800 5.5 100×104Nm3/d Natural Gas
Liquefaction
Mixed Refrigerant Henan Shenghui Special
Equipment Co., Ltd.
In execution
